Overview

Prepare to elevate your listening experience with the new WA33 (2nd generation) amplifier. Building upon the award-winning legacy of its predecessor, our latest masterpiece redefines what's possible in high-fidelity sound reproduction. Unlock unprecedented versatility with expanded output options.

Abyss Headphones considers the WA33 JPS Labs Edition (2nd Gen) to be finest tube headphone amplifier money can buy to mate with their AB-1266 Phi TC headphone, or any other high performance headphones that appreciates high dynamic power and grace.

Sonic Performance That Defies Expectations

The enhanced WA33 "house sound" has been further refined.

• A vivid sound image render each note with precision and articulation

• Extraordinary definition that reveals nuances you've never heard before

• Dramatically improved imaging that precisely places each instrument in three-dimensional space

• An expansive, focused soundstage that transports you to the recording venue

• Breathtaking dynamic range that brings music to life with startling realism

• Crystal-clear articulation that renders every note with perfect precision

Power meets clarity, perfectly balanced. WA33 (2nd Generation) isn't just better. It's a fundamental leap forward in design to deliver a lifetime of enjoyment.

This JPS Labs ABYSS Edition features internal Alumiloy® wiring by JPS Labs, noted for their unique ability to provide life-like clarity and full range coherent sound from the lowest lows to beyond audibility [JPS Labs, the parent company of ABYSS Headphones, designs and manufactures cables for everything ABYSS].

Highlights

• Updated to 2nd generation in May 2025


• JPS Alumiloy® internal wiring

• User selectable outputs:

  • TR (True-ribbon) direct-drive without interface

  • HP (Traditional headphone)

• Headphone Outputs:

  • 4-pin XLR balanced for TR (True-ribbon) without interface

  • 4.4mm balanced (Pentaconn®)

  • 4-pin XLR balanced

  • 6.3mm unbalanced TRS

• Upgraded Tubes: Electro Harmonix Gold pin 6C45Pi driver tubes x 4, Psvane ACME 2A3 power tubes x 4, and Psvane ACME 274B rectifier x 1

• Fully balanced design, Push Pull, Class-A

• Soket tabung Polytetrafluoroethylene (PTFE)

• TKD (Tokyo Ko-on Denpa) 4-channel balanced smooth potentiometer

• Kabel yang digabungkan dengan transformator, kabel Point-to-Point

• Internal Coupling Architecture (ICA)

• Masukan XLR x 2, masukan RCA x 1

• Outputs: Dual 3-pin XLR (left and right channel), 4-pin XLR x 1 and 1/4" (6.3mm)

• User selectable HI/LO impedance for HP headphone

• User selectable HI/LO level for two levels of power output

• Headphones impedance: 0.1—600 Ohms

• Respons frekuensi: 10Hz— 60kHz, -2dB

• Current output (TR): 3.3A [optimized for true ribbon technology]

• Power output (HP): up to 10 watts per channel @32 Ohms [ideal for power-demanding headphones]

• Signal/Noise: > 95 dB, THD: < 0.05%, 1kHz

• Sasis aluminium anodized, tersedia dalam warna hitam atau perak

• Bias diri dengan tabung yang kompatibel [bagan]

• Konsumsi daya: 150w

• Compatible AC voltage: 100v – 240v

• Dimensions: 17.5"(W), 12"(D), 13"(H) with tubes, weight: 54 lbs for Standard, 57 lbs for Elite Edition. Open airflow is required for ventilation.

• Dirancang dan dirakit di New York, AS

• Garansi terbatas tiga tahun[pelajari lebih lanjut]

Di dalam kotak

• WA33 JPS Labs Edition (2nd gen) x 1

• Tubes: Electro Harmonix Gold pin 6C45Pi driver tubes x 4, Psvane ACME 2A3 power tubes x 4, and Psvane ACME 274B rectifier x 1

• Panduan memulai dengan cepat

*Kabel daya AC dan kabel audio tidak disertakan

Each amplifier is hand assembled for you and ships to your door in approximately 2-3 weeks. Recommended cables: JPS Labs Superconductor 4 or best Aluminata XLR interconnects and JPS Labs Kaptovator Lite or best Aluminata AC cables.

PESANAN KHUSUS, BIAYA ANDA TIDAK DAPAT DIBATALKAN, PRODUK TIDAK DAPAT DIKEMBALIKAN. DIPERKIRAKAN 2-3 MINGGU UNTUK PENGIRIMAN.
